Series 0i - Model A Connection manual (Function) Page 861

Connection manual (Function)
B–63503EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
845
Address
Refer-
ence
Item
M
series
T
series
Symbol Signal name
G158 to G161 Axis control data signal (PMC axis control) EID0B to EID31B f f 15.1
G166#0 Auxiliary function completionsignal (PMC axis control) EFINC f f 15.1
G166#2 Buffering disable signal (PMC axis control) EMBUFC f f 15.1
G166#3 Block stop signal (PMC axis control) ESBKC f f 15.1
G166#4 Servo off signal (PMC axis control) ESOFC f f 15.1
G166#5 Axis control temporary stop signal (PMC axis control) ESTPC f f 15.1
G166#6 Reset signal (PMC axis control) ECLRC f f 15.1
G166#7 Axis control command read signal (PMC axis control) EBUFC f f 15.1
G167#0 to #6 Axis control command signal (PMC axis control) EC0C to EC6C f f 15.1
G167#7 Block stop disable signal (PMC axis control) EMSBKC f f 15.1
G168,G169 Axis control feedrate signal (PMC axis control) EIF0C to EIF15C f f 15.1
G170 to G173 Axis control data signal (PMC axis control) EID0C to EID31C f f 15.1
G178#0 Auxiliary function completionsignal (PMC axis control) EFIND f f 15.1
G178#2 Buffering disable signal (PMC axis control) EMBUFD f f 15.1
G178#3 Block stop signal (PMC axis control) ESBKD f f 15.1
G178#4 Servo off signal (PMC axis control) ESOFD f f 15.1
G178#5 Axis control temporary stop signal (PMC axis control) ESTPD f f 15.1
G178#6 Reset signal (PMC axis control) ECLRD f f 15.1
G178#7 Axis control command read signal (PMC axis control) EBUFD f f 15.1
G179#0 to #6 Axis control command signal (PMC axis control) EC0D to EC6D f f 15.1
G179#7 Block stop disable signal (PMC axis control) EMSBKD f f 15.1
G180,G181 Axis control feedrate signal (PMC axis control) EIF0D to EIF15D f f 15.1
G182 to G185 Axis control data signal (PMC axis control) EID0D to EID31D f f 15.1
G192 Each-axis VRDY OFF alarm ignore signal IGVRY1 to IGVRY4 f f 2.8
G198 Position display neglect signal NPOS1 to NPOS4 f f 12.1.10
F000#0 Rewinding signal RWD f f 5.2
F000#4 Feed hold lamp signal SPL f f 5.1
F000#5 Cycle start lamp signal STL f f 5.1
F000#6 Servo ready completionsignal SA f f 2.2
F000#7 Automatic operationsignal OP f f 5.1
F001#0 Alarm signal AL f f 2.4
F001#1 Resetting signal RST f f 5.2
F001#2 Battery alarm signal BAL f f 2.4
F001#3 Distribution end signal DEN f f 8.1
F001#4 Spindle enable signal ENB f f 9.3
F001#5 Tapping signal TAP f f 11.6
F001#7 CNC signal MA f f 2.2
F002#0 Inch input signal INCH f f 11.4
F002#1 Rapid traversing signal RPDO f f 2.7
