Series 0i - Model A Connection manual (Function) Page 97

Connection manual (Function)
B–63503EN–1/01
2. PREPARATIONS FOR OPERATION
81
1324 Coordinate value of stored stored check 3 in the positive direction on each axis
1325 Coordinate value of stored stroke check 3 in the negatice direction on each axis
[Data type] Two–word axis
Increment system IS–B IS–C Unit
Metric input 0.001 0.0001 mm
Inch input 0.0001 0.00001 inch
Rotation axis 0.001 0.0001 deg
[Valid data range] – 99999999 to 99999999
Set the coordinate values of stored stroke checks 3 in the positive and
negative directions for each axis in the machine coordinate system. The
area inside the checks set in the parameters is forbidden.
Number Message Description
502 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) +
side stored stroke check 2.
(Parameter No.1322 )
503 OVER TRAVEL : –n Exceeded the n–th axis (axis 1–8) –
side stored stroke check 2.
(Parameter No.1323)
504 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) +
side stored stroke check 3.
(Parameter No.1324 )
505 OVER TRAVEL : –n Exceeded the n–th axis (axis 1–8) –
side stored stroke check 3.
(Parameter No.1325 )
WARNING
1 In setting a forbidden area, if the two points to be set are the
same, the area is as follows:
(1)When the forbidden area is check 1, all areas are
forbidden areas.
(2)When the forbidden area is check 2 or check 3, all areas
are movable areas.
2 In setting a forbidden area, if the two points are set in the wrong
order, the area is set as follows:
(1) When the forbidden area is check 1, the stroke check becomes
infinite.
(2) When the forbidden area is check 2 or 3, a quadrangle with the
two points assumed as vertexes is set as the check.
[Unit of data]
Alarm and message
Warning
