Series 0i - Model A Connection manual (Function) Page 268

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

252

1423 Feedrate in jog feed for each axis

[Data type] Word axis

When JRV, bit 4 of parameter No. 1402, is set to 1 (feed per revolution) in

T series, specify a feedrate in jog feed (feed per revolution) with an

override of 100% applied to the jog feedrate.

Increment system Unit of data Valid data range

Millimeter machine 0.01 mm/rev

Inch machine 0.001 inch/rev 0 to 32767

Rotation axis 0.01 deg/rev

CAUTION

When the speed of the spindle is low, feedrate fluctuation

may occur. The slower the spindle rotates, the more

frequently feedrate fluctuation occurs.

OPERATOR’S MANUAL

(For Machining Center)

(B–63514EN)

Cutting feed

OPERATOR’S MANUAL

(For Lathe) (B–63504EN)

Cutting feed

[Unit of data]

[Valid data range]

Caution

Reference item
