Series 0i - Model A Connection manual (Function) Page 857

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

841

Address

Refer-

ence

Item

series

Symbol Signal name

G034#0 to G035#3 Spindle motor speed commandsignal R01I2 to R12I2 f f 15.4

G035#5 Spindle motor commandpolarity select signal SGN2 f f 15.4

G035#6 Spindle motor commandpolarity select signal SSIN2 f f 15.4

G035#7 Spindle motor speed command select signal SIND2 f f 15.4

G038#2 Spindle synchronous control signal SPSYC f f 9.11

G038#3 Spindle phase synchronous control signal SPPHS f f 9.11

G038#6 B-axis unclamp completionsignal *BEUCP - f 11.9

G038#7 B-axis clamp completionsignal *BECLP - f 11.9

G039#0 to

#5,G040#0

Tool offset number select signal

OFN0 to OFN5,

OFN6

f - 14.4.2

G039#6

Workpiece coordinate system shift value write mode

select signal

WOQSM f - 14.4.2

G039#7 Tool offset value write mode select signal GOQSM f - 14.4.2

G040#6 Position record signal PRC f - 14.4.1

G040#7 Workpiece coordinatesystem shift value write signal WOSET f - 14.4.2

G041#0 to #3 HS1IA to HS1ID f f

G041#4 to #7 Manual handleinterrupt axis selection signal HS2IA to HS2ID f f 3.3

G042#0 to #3 HS3IA to HS3ID - f

G042#7 Direct operationselect signal DMMC f f 15.6

G043#0 to #2 Mode selection signal MD1,MD2,MD4 f f 2.6

G043#5 DNC operation select signal DNCI f f 5.9

G043#7 Manual reference position return selection signal ZRN f f 4.1

G044#0,G045 Optional block skip signal

BDT1, BDT2 to

BDT9

f f 5.5

G044#1 All-axis machine lock signal MLK f f 5.3.1

G046#1 Single block signal SBK f f 5.3.3

G046#3 to #6 Memory protect signal KEY1 to KEY4 f f 12.2.3

G046#7 Dry run signal DRN f f 5.3.2

G047#0 to #4 TL01 to TL16 f -

G047#0 to #7

Tool group number select signal

TL01 to TL128 - f

10.3

G048#5 Tool skip signal TLSKP f f 10.3

G048#6 Individual tool change reset signal TLRSTI - f 10.3

G048#7 Tool change reset signal TLRST f f 10.3

G049#0 to G050#1 Tool life count override signal *TLV0 to *TLV9 - f 10.3

G053#0 General-purpose integratingmeter start signal TMRON f f 12.1.11

G053#3 Interrupt signal for custom macro UINT f f 11.5.2

G053#6 Error detect signal SMZ f - 7.2.5.3

G053#7 Chamferring signal CDZ f - 11.8

G054,G055 Input signal for custom macro UI000 to UI015 f f 11.5.1

G058#0 External start signal program input MINP f f 13.3
