15. PMC CONTROL FUNCTION
785
Activating memory operation in memory operation mode (MEM) with
the direct operation select signal set to 1 enables machining (direct
operation) while reading a program stored in the personal computer
connected to the HSSB.
[Classification] Input signal
[Function] Selects the mode (direct operation mode) for performing machining while
reading a program stored in the Personal computer connected to the
HSSB.
[Operation] When this signal is set to “1”, the control unit operates as follows:
· When memory operation mode (MEM) is not selected, the control unit
ignores this signal.
· When memory operation mode (MEM) is selected, the control unit
selects direct operation mode and enables direct operation.
FANAC OPEN CNC OPERATOR’S MANUAL (DNC Operation
Management Package) (B–63214EN)
15.6
DIRECT OPERATION
BY Personal
computer connected
to the HSSB
General
Signal
Direct operation select
signal DMMC <G042#7>
Reference Item
Previous page
Next page
