Series 0i - Model A Connection manual (Function) Page 304

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

288

Others f : Can be programmed

: Cannot be programmed

Name

Description

Cycle start/Feed hold

Dry run

Single block

Interlock

Machine lock f When an axis machine lock signal (MLK1 to

MLK4) is turned on or off, acceleration/de-

celeration is not performed on the axis held

under machine lock.

Control–in/control–out com-

mand ( )

Optional block skip command

(/n: n is a number)

Miscellaneous function

(Mxxxx)

f Only the function code signal and function

strobe signal are output.

Spindle function (Sxxxx)

Tool function (Txxxx) f Only the function code signal and function

strobe signal are output.

Second auxiliary function

(Bxxxx)

f Only the function code signal and function

strobe signal are output.

Simple synchronous control f Synchronous control cannot be enabled or

disabled.

Program restart

Tool life management

Macro executor

(execution macro)

MDI operation When G05.1 Q1 is specified in MDI mode,

P/S alarm No. 5113 is issued. The operation

mode cannot be switched to MDI mode in

Look–ahead control (Multiple blocks are

read in advance) mode.

Manual intervention Upon a restart after manual intervention, the

position at which manual intervention oc-

curred must be restored. If the position is not

restored, P/S alarm No. 5114 is issued.

Those functions marked with an asterisk (*) do not perform Look–ahead

control of multiple blocks.

Before G05.1 Q1, the following modal codes must be specified. If this

condition is not satisfied, P/S alarm No. 5111 will be issued.

G code Description

G00

G01

G02

G03

Positioning

Linear interpolation

Circular interpolation (CW)

Circular interpolation (CCW)

G15 Polar coordinate command cancel

Conditions for entering

Look–ahead control

(Multiple blocks are read

in advance)
