Series 0i - Model A Connection manual (Function) Page 829

Connection manual (Function)
B–63503EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
813
Function Section
M
series
T
series
AddressSymbolSignal name
Servo off
(mechanical handle)
Servo off signals SVF1 to SVF4 G126 f f
1.2.7
Cycle start signal ST G007#2 f f
Feed hold signal *SP G008#5 f f
Cycle start/feed hold Automatic operation signal OP F000#7 f f
5.1
Cycle start lamp signal STL F000#5 f f
Feed hold lamp signal SPL F000#4 f f
Cs contour control change signal CON G027#7 f f
Cs contour control
Cs contour control change completion
signal
FSCSL F044#1 f f
9.8
Outputting the
Axis moving signals MV1 to MV4 F102 f f
movement state of
an axis Axis moving direction signals MVD1 to MVD4 F106 f f
1.2.4
Actual spindle speed
output
Actual spindle speed signals AR0 to AR15 F040, F041 f —
9.6
Constant surface
speed control
Constant surface speed signal CSS F002#2 f f
9.4
Spindle stop completion signal SPSTP G028#6 f —
Spindle unclamp signal SUCLP F038#1 f —
Spindle positioning Spindle unclamp completion signal *SUCPF G028#4 f —
9.7
Spindle clamp signal SCLP F038#0 f —
Spindle clamp completion signal *SCPF G028#5 f —
Spindle orientation external stop
SHA00 to SHA11
G078#0 to
G079#3
f f
Spindle orientation
Spindle orientation external stop
position command signals
SHB00 to SBH11
G080#0 to
G081#3
f f
9.12
Torque limit command LOW signals
TLMLA G070#0 f f
Torque limit command LOW signals
(serial spindle)
TLMLB G074#0 f f
Torque limit command HIGH signals
TLMHA G070#1 f f
Torque limit command HIGH signals
(serial spindle)
TLMHB G074#1 f f
CTH1A, CTH2A G070#3, #2 f f
Clutch/gear signals (serial spindle)
CTH1B, CTH2B G074#3, #2 f f
SRVA G070#4 f f
Spindle serial
CCW command signals (serial spindle)
SRVB G074#4 f f
output/spindle
analog output
SFRA G070#5 f f
9.2
CW command signals (serial spindle)
SFRB G074#5 f f
Orientation command signals
ORCMA G070#6 f f
Orientation command signals
(serial spindle)
ORCMB G074#6 f f
MRDYA G070#7 f f
Machine ready signals (serial spindle)
MRDYB G074#7 f f
ARSTA G071#0 f f
Alarm reset signals (serial spindle)
ARSTB G075#0 f f
