6. INTERPOLATION FUNCTION
B–63503EN–1/01
218
5142 Repetition count of final finishing in the multiple repetitive canned cycle G76
[Data type] Two–word
[Unit of data] Cycle
[Valid data range] 1 to 99999999
This parameter sets the repetition count in the multiple repetitive canned
cycle G76.
5143 Tool nose angle in the multiple repetitive canned cycle G76
[Data type] Two–word
[Unit of data] Degree
[Valid data range] 0 to 120 (When FS10/11 TAPE FORMAT is used)
0, 29, 30, 55, 60, 80 (When FS10/11 TAPE FORMAT is not used)
This parameter sets the tool nose angle in the multiple repetitive canned
cycle G76.
WARNING
During threading, stopping feed without stopping the
spindle is dangerous because the cutting depth will abruptly
increase. Feed hold is, therefore, disabled during
threading. If attempted during threading, feed stops in the
same way as single block stop upon the completion of the
first non–threading block after the termination of threading
mode. The feed hold lamp (SPL lamp), however, lights
immediately after the feed fold button (on the machine
operator’s panel) is pressed. The lamp goes off when feed
stops (the CNC enters the single block stop state).
Setting the repetition
count of finishing for the
multiple repetitive
canned cycle G76
Setting the tool angle for
the multiple repetitive
canned cycle G76
Warning
Previous page
Next page
