B–63503EN–1/01

15. PMC CONTROL FUNCTION

733

[Classification] Input signal

[Function]

IS–B IS–C Unit

Metric input

Degree input

0.001 0.0001 mm

deg

Inch input 0.0001 0.00001 inch

[Valid data range]

(1) Rapid traverse (EC0g to EC6g: 00h)

(2) Cutting feed – feed per minute (EC0g to EC6g: 01h)

(3) Cutting feed – feed per rotation (EC0g to EC6g: 02h)

(4) Skip – feed per minute (EC0g to EC6g: 03h)

For these commands, signals EID0g to EID31g are used to specify, in

binary format, the incremental moving distance, according to the input

increment used for the axis.

IS–B IS–C Unit

Metric input

Degree input

"99999.999 "9999.9999 mm

deg

Inch input "9999.9999 "999.99999 inch

When diameter programming is specified with bit 3 (DIAx) of parameter

No. 1006, bit 1 (CDI) of parameter No. 8005 can be used to specify

whether a radius or diameter is to be used in a command.

(5) Dwell (EC0g to EC6g: 04h)

For this command, the signals are used to specify, in binary format,

the dwell time.

Data range Unit

1 to 9999999 ms

When diameter programming is specified with bit 3 (DIAx) of

parameter No. 1006, bit 1 (CDI) of parameter No. 8005 can be used

to specify whether a radius or diameter is to be used in a command.

NOTE

When the increment system IS–C is used, the least input

increment for the dwell time can be set to 0.1 ms, according

to the setting of bit 1 (DWE) of parameter No. 8002.

(6) Continuous feed (EC0g to EC6g: 06h)

For this command, signal EID31g is used to specify the direction of

continuous feed, as follows:

0: Positive direction

1: Negative direction

4 Axis control data

signals

EID0g to EID31g

[Unit of data]
