B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

438

During spindle synchronization or simplified synchronization control,

the second spindle operates in phase with the first spindle. Multi-spindle

control for the first spindle can be used during synchronization control,

but multi-spindle control for the second spindle is disabled.

Using the spindle selection signal (SWS 1–2), rigid tapping can use either

the first or second spindle as the rigid tap spindle. There are certain

restrictions:

D Set the SWS 1 to 2 signals before directing rigid tapping;

D Do not switch the SWS 1 to 2 signals during rigid tapping; and

D Use the appropriate ENB signal (either ENB or ENB2) for the selected

spindle as the ENB signal for the rigid tapping PMC sequence.

The spindles not used for rigid tapping can be rotated at a speed specified

before rigid tapping starts, or can be stopped.

[Classification] Input signal

[Function] Controls whether S command specified to the NC is output to the spindle

or not in multi-spindle.

SWS1 1 : Outputs a speed command to the first spindle.

0 : Outputs no speed command to the first spindle.

SWS2 1 : Outputs a speed command to the second spindle.

0 : Outputs no speed command to the second spindle.

[Classification] Input signal

[Function] Effective only to multi-spindle, each spindle can be stopped by this signal.

*SSTP1 1 : Does not set 0 min

–1

for output to the first spindle.

0 : Sets 0 min

–1

for output to the first spindle.

*SSTP2 1 : Does not set 0 min

–1

for output to the second spindle.

0 : Sets 0 min

–1

for output to the second spindle.

D Spindle synchronization

and simplified

synchronization control

D Rigid tapping

Signal

Spindle Selection Signal

SWS1, SWS2 <G027#0,

#1>

Individual spindle stop

signal *SSTP1, *SSTP2

<G027#3, #4>
