Series 0i - Model A Connection manual (Function) Page 294

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

278

1432 Maximum cutting feedrate for each axis in the advanced preview control mode

[Data type] Two–word axis

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-B IS-C

Millimeter machine 1 mm/min 0 – 240000 0 – 100000

Inch machine 0.1 inch/min 0 – 96000 0 – 48000

Rotation axis 1 deg/min 0 – 240000 0 – 100000

Specify the maximum cutting feedrate for each axis in the advanced

preview control mode.

A feedrate for each axis is clamped during cutting feed so that it does not

exceed the maximum cutting feedrate specified for each axis.

NOTE

1 This parameter is effective only in linear and circular

interpolation. In polar coordinate, cylindrical, and involute

interpolation, the maximum feedrate for all axes specified in

parameter No. 1431 is effective.

2 If a setting for each axis is 0, the maximum feedrate

specified in parameter No. 1431 is applied to all axes and

the feedrate is clamped at the maximum feedrate.

3 In a mode other than the advanced preview mode, the

maximum cutting feedrate specified in parameter No. 1422

or No. 1430 is applied and the feedrate is clamped at the

maximum feedrate.

1602

LS2

#5 #4

CSD

#3 #2 #1 #0

FWB

[Data type] Bit

FWB Cutting feed acceleration/deceleration before interpolation

0 : Type A of acceleration/deceleration before interpolation is used.

1 : Type B of acceleration/deceleration before interpolation is used.

Type A: When a feedrate is to be changed by a command, acceleration/

deceleration starts after the program enters the block in which

the command is specified.

Type B: When a feedrate is to be changed by a command, deceleration

starts and terminates at the block before the block in which the

command is specified.

[Unit of data]

[Valid data range]
