B–63503EN–1/01

5. AUTOMATIC OPERATION

177

NOTE

To specify the maximum cutting feedrate for each axis, use

parameter No. 1430 instead.

OPERATOR’S MANUAL

(For Machining Center)

(B–63514EN)

Dry run

OPERATOR’S MANUAL

(For Lathe) (B–63504EN)

Dry run

Single block operation is valid only for automatic operation.

When the single block signal (SBK) is set to 1 during automatic operation,

the CNC enters the automatic operation stop state after executing the

current block. In subsequent automatic operation, the CNC enters the

automatic operation stop state after executing each block in the program.

When the single block signal (SBK) is set to 0, normal automatic

operation is restored.

Single block operation during the execution of custom macro statements

depends on the setting of bit 5 (SBM) of parameter No. 6000, as follows:

SBM = 0: Operation does not stop in the custom macro statements but

stops once the next NC command has been executed.

SBM = 1: Operation stops after each block in the custom macro

statements.

When the CNC is in the automatic operation stop state during single block

operation, the mode can be changed to manual data input (MDI), manual

handle feed (HND), incremental feed (INC), or jog feed (JOG), by using

the mode select signals (MD1, MD2, and MD4).

Reference item

5.3.3

Single Block
