Series 0i - Model A Connection manual (Function) Page 542

Connection manual (Function)

Page of 874

/ 874

10. TOOL FUNCTIONS

B–63503EN–1/01

526

When tools are classified into several groups, average tool life (No. of

uses or time) is designated for each group. Whenever a tool is used, the

usage time is subtracted from the tool life; when the tool life expires, the

next tool in the group is selected. The tool sequence within a group is

arranged in advance.

The end of a tool’s life is reported by tool change signal TLCH or

individual tool change signal TLCHI. Tool change signal TLCH is set to

1 at the end of the life of the last tool of a group. Individual tool change

signal TLCHI is set to 1 at the end of the life of the current tool.

[Classification] Output signal

[Function] Reports the end of the life of the last tool of a group.

[Output condition] The signal is set to 1 when:

· The life of the last tool of a group ends, after tool change has been

performed each time the end of the life of each tool in a group is

detected.

The signal is set to 0 when:

· Tool–change reset is completed for all groups in which no available

tools remain.

NOTE

The TLCH signal turns to “1” when the CNC is reset by M02

or M30, for instance after the tool life, based on the

frequency of times used, is reached. When tool life is

specified by usage time, TLCH turns to “1” when the tool life

limit is reached. The signal will change during machine

operation, but machining will continue until the end of the

program.

[Classification] Input signal

[Function] Clears all executable data, including the life count of the group, *, and @.

To clear the data, specify a group number by tool group number selection

signal after replacing the worn–out tools that are displayed on the CRT.

The data can also be cleared from the MDI.

10.3

TOOL LIFE

MANAGEMENT

General

Signal

Tool change signal

TLCH <F064#0>

Tool change reset signal

TLRST <G048#7>
