Series 0i - Model A Connection manual (Function) Page 707

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

14. MEASUREMENT

691

NOTE

1 The skip signal width requires at least 10 msec.

2 The CNC directly reads the skip signal SKIP<X004#7> from

the machine tool; the PMC no longer requires to process the

signal.

3 If the skip function G31 is not used, the PMC can use the

signal terminal SKIP<X004#7> corresponding to the skip

signal as a general purpose input signal.

SKIPX1004

#6 #5 #4 #3 #2 #1 #0

G006

SKIPP

#5 #4 #3 #2 #1 #0

SKF6200

SKF

#6 #5 #4 #3 #2 #1

SK0

GSK

[Data type] Bit type

GSK In skip cutting (G31), the signal SKIPP (bit 6 of G006) is:

0 : Not used as a skip signal.

1 : Used as a skip signal.

SK0 This parameter specifies whether the skip signal is made valid under the

state of the skip signal SKIP (bit 7 of X1004).

0 : When these signals are 1, they are assumed to be input (skip).

1 : When these signals are 0, they are assumed to be input (skip).

SKF Dry run, override, and automatic acceleration/deceleration for G31 skip

command

0 : Disabled

1 : Enabled

Number Message Description

035 CAN NOT COMMANDED

G31

(T series)

Skip cutting (G31) was specified in tool

nose radius compensation mode.

Modify the program.

036 CAN NOT COMMANDED

G31

(M series)

Skip cutting (G31) was specified in cut-

ter compensation mode.

Modify the program.

Signal address

Parameter

Alarm and message
