15. PMC CONTROL FUNCTION

B–63503EN–1/01

772

NOTE

1 This function can be used only in memory operation. It

cannot be used during DNC operation and MDI operation.

2 Select the program number from O001 to O031 or O0001

to O9999.

3 Program numbers from O0001 to O9999 can be used.

However, programs corresponding to all the program

numbers do not have to be stored in memory.

4 When a program corresponding to the specified program

number is not stored in memory, an alarm (No. 059) is

activated when the start button is pressed.

5 Program search is performed only when the start button is

pressed in the reset state. When the CNC is in the

automatic operation stop state (single block stop, etc.) or

pause state (feedhold stop, etc.), program search is not

performed even if the start button is pressed and execution

is started from the point specified by the present execution

pointer.

6 To restart program halfway through, press the start button

after sequence number search in MEM mode. The

workpiece number search is not performed; program

execution starts from the block which is searched by

sequence number search, because the OP signal is set by

sequence number search in MEM mode and the CNC reset

state is released.

7 When the start button is pressed with all workpiece number

search signals are “0”, program search is not performed but

execution is started from the point specified by the present

execution pointer. To restart operation from the start of a

program which cannot be searched by this function, perform

the usual program number search operation (CRT/MDI

panel operation), turn all the workpiece number search

signals to “0” and press the start button

Note
