B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

492

5221 Number of gear teeth on the spindle side in rigid tapping (First gear)

5222 Number of gear teeth on the spindle side in rigid tapping (Second gear)

5223 Number of gear teeth on the spindle side in rigid tapping (Third gear)

5224 Number of gear teeth on the spindle side in rigid tapping (Fourth gear)

[Data type] Word

[Valid data range] 1 to 32767

These parameters set the number of gear teeth on the spindle side for every

gear when any gear ratio is set in rigid tapping.

NOTE

This parameter is valid when VGR, #1 of parameter No.

5200, is “1”.

Set the same value to parameter Nos. 5221 to 5224 when

the spindle has a position coder.

5231 Number of gear teeth on the position coder side in rigid tapping (First gear)

5232 Number of gear teeth on the position coder side in rigid tapping (Second gear)

5233 Number of gear teeth on the position coder side in rigid tapping (Third gear)

5234 Number of gear teeth on the position coder side in rigid tapping (Fourth gear)

[Data type] Word

[Valid data range] 1 to 32767

These parameters set the number of gear teeth on the position coder side

for every gear when any gear ratio is set in rigid tapping.

NOTE

This parameter is valid when VGR, #1 of parameter No.

5200, is “1”.

Set the same value to parameter Nos. 5231 to 5234 when

the spindle has a position coder.

A spindle motor incorporating the position coder uses a

position coder with 2048 pulses per revolution. In this case,

set the value that is two times as many as the actual number

of gear teeth (because of conversion to 4096 pulses per

revolution).
