Series 0i - Model A Connection manual (Function) Page 850

Connection manual (Function)
B–63503EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
834
Group
Refer-
ence
item
M
series
T
series
Address Signal nameSymbol
PC1DEA
Signal indicatingthe status of the detected
F047#0 f f
PC1DEB
Signal indicatingthe status of the detected
one-rotation position coder signal (serial spindle)
F051#0 f f
9.2
PC2SLC 2nd positioncoder selection signal G028#7 f - 9.9
PN1,PN2,PN4,PN8,
PN16
Workpiece number search signal G009#0 to 4 f f 15.3
PORA2A
Signal for approximatespindle orientationwith a
F046#5 f f
P PORA2B
Signal for approximatespindle orientationwith a
position coder (serial spindle)
F050#5 f f
9.2
PRC Position record signal G040#6 f - 14.4.1
PRGDPL program screen display mode signal F053#1 f f 15.5
PRTSF Target parts count reached signal F062#7 f f 12.1.11
PSW01 to PSW10 Position switch signal
F070#0 to
F071#1
f f 1.2.8
PSYN Polygon synchronization under way signal F063#7 f - 6.9
R01I to R12I
G032#0 to
G033#3
f f
R01I2 to R12I2
Spindle motor speed command signal
G034#0 to
G035#3
f f
15.4
R01O to R12O S12-bit code signal
F036#0 to
F037#3
f f 9.3
RCFNA F046#3 f f
RCFNB
Output switch completionsignal (serial spindle)
F050#3 f f
9.2
RCHA G071#7 f f
RCHB
Power line status check signal (serial spindle)
G075#7 f f
9.2
RCHHGA
High–output MCC status signal while a magnetic
G072#7 f f
RCHHGB
High–output MCC status signal while a magnetic
sensor (serial spindle)
G076#7 f f
9.2
R
RCHPA F046#2 f f
RCHPB
Output switch signal (serial spindle)
F050#2 f f
9.2
RGSPM F065#1 - f
RGSPP
Spindle rotation direction signal
F065#0 - f
9.10
RGTAP Rigid tapping signal G061#0 f f 9.10
RGTSP1,RGTSP2 Rigid tapping spindle selection signal G061#4,#5 f - 9.10
RLSOT Strok check release signal G007#7 - f 2.3.2
RLSOT3 Stroke check 3 release signal G007#4 f - 2.3.3
ROTAA
Rotation direction command while changing the
G072#1 f f
ROTAB
Rotation direction command while changing the
orientation stop position signal (serial spindle)
G076#1 f f
9.2
ROV1,ROV2 Rapid traverse override signal G014#0,#1 f f 7.1.6.1
