B–63503EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

822

Function Section

series

AddressSymbolSignal name

SIND G033#7 f f

Spindle motor speed command

selection signals

SIND2 G035#7 f f

selection signals

SIND3 G037#7 f f

R01I to R12I

G032#0 to

G033#3

f f

Spindle motor speed command signals R01I2 to R12I2

G034#0 to

G035#3

f f

Spindle output

control by the PMC

R01I3 to R12I3

G036#0 to

G037#3

f f

15.4

SSIN G033#6 f f

Spindle motor command polarity

selection signals

SSIN2 G035#6 f f

selection signals

SSIN3 G037#6 f f

SGN G033#5 f f

Spindle motor command polarity

command signals

SGN2 G035#5 f f

command signals

SGN3 G037#5 f f

*ESP G008#4 f f

Emergency stop Emergency stop signal

*ESP X1008#4 f f

2.1

All–axis VRDY off alarm ignore signal IGNVRY G066#0 f f

VRDY off alarm

ignore signal

Each–axis VRDY off alarm ignore

signal

IGVRY1 to IGVRY4 G192 f f

2.8

Follow–up Follow–up signal *FLWU G007#5 f f

1.2.6

Program restart signal SRN G006#0 f f

Program restart

Program restart under way signal SRNMV F002#4 f f

5.7

Position switch Position switch signals PSW01 to PSW10

F070#0 to

F071#1

f f

1.2.8

Miscellaneous function code signals M00 to M31 F010 to F013 f f

Miscellaneous function strobe signal MF F007#0 f f

DM00 F009#7 f f

DM01 F009#6 f f

Decode M signals

DM02 F009#5 f f

DM30 F009#4 f f

Spindle function code signals S00 to S31 F022 to F025 f f

Miscellaneous

function/2nd auxiliary

Spindle function strobe signal SF F007#2 f f

8.1

function

Tool function code signals T00 to T31 F026 to F029 f f

Tool function strobe signal TF F007#3 f f

2nd auxiliary function code signals B00 to B31 F030 to F033 f f

BF F007#4 f —

2nd auxiliary function strobe signal

BF F007#7 — f

End signal FIN G004#3 f f

Distribution end signal DEN F001#3 f f
