B–63503EN–1/01

12. DISPLAY/SET/EDIT

613

Time is displayed in the hour/minute/second format on each display

screen. Some screens allows display of the year, month, and day.

The custom macro system variable can be used to read the time. The time

will be told through the window on the PMC side.

Time information can be read and written.

System variables for time information

Variable

number

Function

#3001 This variable functions as a timer that counts in 1–millisecond in-

crements at all times. When the power is turned on, the value

of this variable is reset to 0. When 65535 milliseconds is

reached, the value of this timer returns to 0.

#3002 This variable functions as a timer that counts in 1–hour incre-

ments when the cycle start lamp is on. This timer preserves its

value even when the power is turned off. When 1145324.612

hours is reached, the value of this timer returns to 0.

#3011 This variable can be used to read the current date (year/month/

day). Year/month/day information is converted to an apparent

decimal number. For example, Janualy 23, 2000 is represented

as 20000123.

#3012 This variable can be used to read the current time (hours/min-

utes/seconds). Hours/minutes/seconds information is con-

verted to an apparent decimal number. For example, 34 minutes

and 56 seconds after 3 p.m. is represented as 153456.

OPERATOR’S MANUAL (For Machining

Center) (B–63514EN)

Displaying and Setting Run Time, Parts

Count, and Time

OPERATOR’S MANUAL (For Lathe)

(B–63504EN)

Displaying and Setting Run Time, Parts

Count, and Time

12.1

DISPLAY/SET

12.1.1

Clock Function

General

Reference item
