9. SPINDLE SPEED FUNCTION

428

1022 Setting of each axis in the basic coordinate system

[Data type] Byte axis

Only one axis can be set for each of the three basic axes X, Y, and Z, but

two or more parallel axes can be set.

Set value Meaning

0 Neither the basic three axes nor a parallel axis

1 X axis of the basic three axes

2 Y axis of the basic three axes

3 Z axis of the basic three axes

5 Axis parallel to the X axis

6 Axis parallel to the Y axis

7 Axis parallel to the Z axis

Set 0 to the Cs contour control axis.

1023 Number of the servo axis for each axis

[Data type] Byte axis

Set the servo axis for each control axis.

Generally, the same number shall be assigned to the control axis and the

corresponding servo axis.

Set –1 as the number of servo axis to the Cs contour control axis.

1250 Coordinate value of the reference position used when automatic coordinate system

setting is performed

[Data type] Two–word axis

Set the coordinate value of the reference position on each axis to be used

for setting a coordinate system automatically.

1420 Rapid traverse rate for each axis

[Data type] Word axis

[Unit of data] 1 deg/min

[Valid data range] 30 to 240000 (IS–A, IS–B)

30 to 120000 (IS–C)

Set the rapid traverse rate when the rapid traverse override is 100% for

each axis.
