11. PROGRAM COMMAND

B–63503EN–1/01

558

#7 #6 #5 #4 #3 #2 #1 #0

*76010 *6 *5 *4 *3 *2 *1 *0

=76011 =6 =5 =4 =3 =2 =1 =0

#76012 #6 #5 #4 #3 #2 #1 #0

[76013 [6 [5 [4 [3 [2 [1 [0

]76014 ]6 ]5 ]4 ]3 ]2 ]1 ]0

[Data type] Bit

These parameters are used to input/output macro statements with EIA

code.

The numeral of a suffix indicates the bit position in a code.

*0 to *7 Set the hole pattern of an EIA code indicating *.

=0 to =7 Set the hole pattern of an EIA code indicating =.

#0 to#7 Set the hole pattern of an EIA code indicating #.

[0 to [7 Set the hole pattern of an EIA code indicating [.

]0 to ]7 Set the hole pattern of an EIA code indicating ].

0 :Corresponding bit is 0

1 :Corresponding bit is 1.

6030 M code that calls the program entered in file

[Data type] Byte

[Valid data range] 0, and 1 to 255

When the subprogram call function is used, this parameter sets the M code

for calling a program in a file stored on the external input/output device.

NOTE

The M code is judged to be M198 when zero is specified as

the setting value.

D Setting when macro

statement is input/output

with EIA code

D Setting an M code that

calls a program entered

in a file
