B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

411

#7 #6 #5 #4 #3 #2 #1 #0

4000 RETRN

[Data type] Bit

RETRN Reference position return direction of spindle.

0 : CCW (Counter clockwise)

1 : CW (Clockwise)

NOTE

The direction for spindle orientation (or reference position

return) in spindle positioning using a serial spindle is

determined by this parameter.

4044 Velocity loop proportion gain in servo mode (High gear)

4045 Velocity loop proportion gain in servo mode ( Low gear)

[Data type] Word

[Unit of data]

[Valid data range] 0 to 32767

This parameter sets a velocity loop proportional gain in servo mode

(spindle positioning, rigid tapping, etc.)

NOTE

Set this parameter when serial spindle is used.

4052 Velocity loop integral gain in servo mode (High gear)

4053 Velocity loop integral gain in servo mode (Low gear)

[Data type] Word

[Unit of data]

[Valid data range] 0 to 32767

This parameter sets a velocity loop integral gain in servo mode (spindle

positioning, rigid tapping, etc.)

NOTE

Set this parameter when serial spindle is used.
