Series 0i - Model A Connection manual (Function) Page 429

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

413

#7 #6 #5 #4 #3 #2 #1 #0

IMB4950 ESI TRV ISZ IDM IOR

[Data type] Bit

IOR Resetting the system in the spindle positioning mode

0 : Does not releases the mode.

1 : Releases the mode

IDM The positioning direction for the spindle using a M code is

0 : The positive direction

1 : The negative direction

ISZ When an M code for spindle orientation is specified in spindle

positioning:

0 : The spindle rotation mode is cleared and the mode is switched to the

spindle positioning mode, and spindle orientation operation is

performed.

1 : The spindle rotation mode is cleared and the mode is switched to the

spindle positioning mode but spindle orientation operation is not

performed.

TRV Direction of rotation of spindle positioning

0 : Normal

1 : Reverse

ESI Selection of a spindle positioning specification

0 : The conventional specificaion is used.

1 : The extended specificaion is used.

NOTE

The extended specification includes the following two

extensions:

D With the conventional specification, the number of M

codes for specifying a spindle positioning angle is always

6. With the extended specification, an arbitrary number

of such M codes from 1 to 256 can be selected by

parameter setting (See parameter No. 4964.)

D The maximum feedrate for spindle positioning (setting of

parameter No. 1420) can be extended from 240000 to

269000 (unit: 10 deg/min).

IMB When the spindle positioning function is used, half–fixed angle

positioning based on M codes uses:

0 : Specification A

1 : Specification B
