9. SPINDLE SPEED FUNCTION

444

NOTE

1 The spindle orientation signal, spindle speed override

signals, and spindle stop signal *SSTP only function for

selected signals.

2 The S 12-bit code signals R01O to R12O outputs the state

of a selected spindle. If two or more spindles are selected

at the same time, the states of the first and second spindles

are output in this order.

3 The multi-spindle function allows two position coder

interfaces to be used. But the number of actual speed

indications on the CNC screen does not change. The speed

based on the feedback information of the selected position

coder is displayed.

4 An SOR command has priority over S commands and

SIND-based rotation control from the PMC, and will cause

all selected spindle to perform orientation rotation.

Note
