Series 0i - Model A Connection manual (Function) Page 853

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

837

Group

Refer-

ence

item

series

Address Signal nameSymbol

T00 to T31 Tool function code signal F026 to F029 f f 8.1

TAP Tapping signal F001#5 f f 11.6

TF Tool function strobe signal F007#3 f f 8.1

TFIN Tool function completionsignal G005#3 f f 8.4

THRD Thread cutting signal F002#3 f f 6.4.1

TL01 to TL16 G047#0 to #4 f -

TL01 to TL128

Tool group number select signal

G047#0 to #7 - f

10.3

TLCH Tool change signal F064#0 f f 10.3

TLCHI Individualtool change signal F064#2 - f 10.3

TLMA F045#6 f f

T TLMB

Torque limit signal (serial spindle)

F049#6 f f

9.2

TLMHA G070#1 f f

TLMHB

Torque limit command HIGH signal (serial spindle)

G074#1 f f

9.2

TLMLA G070#0 f f

TLMLB

Torque limit command LOW signal (serial spindle)

G074#0 f f

9.2

TLNW New tool select signal F064#1 f f 10.3

TLRST Tool change reset signal G048#7 f f 10.3

TLRSTI Individual tool change reset signal G048#6 - f 10.3

TLSKP Tool skip signal G048#5 f f 10.3

TMRON General-purpose integratingmeter start signal G053#0 f f 12.1.11

TRQL1 to TRQL4 Torque limit reached signal F114 f - 14.4.3

UI000 to UI015 Input signal for custom macro G054,G055 f f 11.5.1

UINT Interrupt signal for custom macro G053#3 f f 11.5.2

UO000 to UO015 F054,F055 f f

UO100 to UO131

Output signal for custom macro

F056 to F059 f f

11.5.1

WOQSM

Workpiece coordinate system shift value write

mode select signal

G039#6 f - 14.4.2

WOSET

Workpiece coordinate system shift value write

signal

G040#7 f - 14.4.2
