A. INTERFACE BETWEEN CNC AND PMC
836
Group
Refer-
ence
item
M
series
T
series
Address Signal nameSymbol
Skip signal X1004#7 f f 14.3.1
SKIP
Overload torque signal X1004#7 - f 11.13
SKIPP Skip signal G006#6 f - 14.3.1
SLVA G073#1 f f
SLVB
Slave operation command signal (serial spindle)
G077#1 f f
9.2
SLVSA F046#4 f f
SLVSB
Slave operation status signal (serial spindle)
F050#4 f f
9.2
SMZ Error detect signal G053#6 f - 7.2.5.3
SOCNA
/
G071#4 f f
SOCNB
Soft start
/
stop cancel signal (serial spindle)
G075#4 f f
9.2
SOR Spindle orientationsignal G029#5 f f 9.3
SOV0 to SOV7 Spindle speed override signal G030 f f 9.3
SPAL Spindle fluctuation detectionalarm signal F035#0 f – 9.5
SPL Feed hold lamp signal F000#4 f f 5.1
SPO Software operator's panel signal(*SP) F075#7 f f 12.1.14
SPPHS Spindle phase synchronous control signal G038#3 f f 9.11
SPSLA G071#2 f f
SPSLB
Spindle select signal (serial spindle)
G075#2 f f
9.2
SPSTP Spindle stop complete signal G028#6 f - 9.7
S SPSYC Spindle synchronous control signal G038#2 f f 9.11
SRN Program restart signal G006#0 f f 5.7
SRNMV Program restart under way signal F002#4 f f 5.7
SRVA G070#4 f f
SRVB
CCW commandsignal (serial spindle)
G074#4 f f
9.2
SSIN G033#6 f f
SSIN2
Spindle motor command polarity select signal
G035#6 f f
15.4
SSTA F045#1 f f
SSTB
Speed zero signal (serial spindle)
F049#1 f f
9.2
ST Cycle start lamp signal G007#2 f f 5.1
STL Cycle start signal F000#5 f f 5.1
STLK Start lock signal G007#1 f - 2.5
SUCLP Spindle unclampsignal F038#1 f - 9.7
SVF1 to SVF4 Servo off signal G126 f f 1.2.7
SWS1 G027#0 f -
SWS2
Spindle selection signal
G027#1 f -
9.9
SYCAL Spindle synchronous control alarm signal F044#4 f f 9.11
SYCAL Phase error monitor signal F044#4 f f 9.11
SYNC1 to SYNC4 Simple synchronous axis select signal G138 - f 1.6
SYNCJ1 to SYNCJ4 Simple synchronous manual feed axis select signal G140 - f 1.6
