15. PMC CONTROL FUNCTION

B–63503EN–1/01

764

The external workpiece coordinate system shift adjusts the workpiece

coordinate system depending on the shift amount set via PMC. Each axis

(parameter No. 1220) has this shift amount, and it is added to all the

workpiece coordinate systems for use. The shift amount is not lost by cut

off of the power supply. It is not added incrementally, but each input shift

amount makes a new shift amount. The amount that can be input is

0-"7.999 mm or "0.7999 inch.

The machine coordinate system can be shifted by inputting shift value.

When the shift amount is input, compensation is immediately applied to

the corresponding axis and the machine starts operation. The position

accuracy can be improved by combining this function with the sensor.

The specification method for the axis to be shifted is the same as that for

the external workpiece coordinate system shift.

The compensation value is specified for the signals ED0 to ED15 by a

binary code ranging from 0 to "9.999. This compensation value should

be absolute and the amount which the machine actually moves on input

is the difference from the previously stored value. When a large amount

of compensation is applied at a time, an alarm such as “excessive error on

stop” may occur. In this case, input the compensation amount several

times.

(a) External alarm message

The external alarm message holds the CNC under an alarm

condition by sending an alarm number from the external unit, as

well as a message that is displayed on the CRT screen of the CNC.

Up to four alarm numbers and messages can be sent at a time; the

alarm number ranges from 0 to 999, and the CNC displays it with

1000 added. The message for one alarm number can be up to 32

characters long. The alarm condition is reset by external data.

(b)External operator message

The external operator message sends the operator message and

number from the external unit to the CNC, with a display on the

CRT screen of the CNC.

Only one message can be transmitted, with a potential message

length of 255 characters. The alarm number ranges from 0 to 999;

from 0 to 99, the CNC adds 2000 to the number, while from 100

to 999 the number is not displayed, only the message is displayed.

Data specification method in external message

Item

ED15 to ED0

(binary)

Alarm set 1 0 0 0 0 0 0 Alarm No.

Alarm clear 1 0 0 0 0 0 1 Alarm No.

Operator mes-

sage list

1 0 0 0 1 0 0 Message No.

Operator mes-

sage clear

1 0 0 0 1 0 1 Message No.

Message 1 0 0 0 × 1 1 Character

(Note)

3) External workpiece

coordinate system

shift

4) External machine

coordinate system

shift

5) External alarm

message
