Series 0i - Model A Connection manual (Function) Page 227

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

6. INTERPOLATION FUNCTION

211

3402

#6 #5 #4 #3 #2

G19

G18

[Data type] Bit

G18 and G19 Plane selected when power is turned on or when the control is cleared

G19 G18 G17, G18 or G19 mode

0 0 G17 mode (plane XY)

0 1 G18 mode (plane ZX)

1 0 G19 mode (plane YZ)

3410 Tolerance of arc radius

[Data type] Two–word

Increment system IS–B IS–C Unit

Metric input 0.001 0.0001 mm

Inch input 0.0001 0.00001 inch

[Valid data range] 1 to 99999999

When a circular interpolation command (G02, G03) is executed, the

tolerance for the radius between the start point and the end point is set. If

the difference of radii between the start point and the end point exceeds the

tolerance set here, a P/S alarm No. 20 is informed.

NOTE

When the set value is 0, the difference of radii is not

checked.

[Unit of data]
