Series 0i - Model A Connection manual (Function) Page 635

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

12. DISPLAY/SET/EDIT

619

Waveform diagnosis is classified into two main types.

(1)One–shot type

One–shot waveform diagnosis provides graphs of waveforms to

illustrate changes in the following data.

In one–shot waveform diagnosis, the start of data collection can be

triggered by the rising or falling edge of a machine signal.

This function is designed to facilitate the adjustment of servo motors

and spindle motors.

a. Servo motor error value along each axis, number of distributed

pulses, torque, feedrate, current, and thermal simulation data

b. Combined feedrate for the first, second, and third axes

c. Spindle motor speed, load meter reading, and position deviation,

converted to spindle position

d. On/off status of the machine signal, specified by a signal address

(2)Stored type

In stored waveform diagnosis, changes in the following data are

recorded. When a servo alarm is issued, the recorded data can be read

and displayed graphically as a waveforms.

In stored waveform diagnosis, the end of data collection can be

triggered by the rising or falling edge of a machine signal.

This function is designed to facilitate the determination of a faulty

location.

Stored data can be output via the reader/punch interface.

a. Servo motor error value along each axis, number of distributed

pulses, torque, feedrate, current, and thermal simulation data

#7 #6 #5 #4 #3 #2 #1 #0

3112 SGD

NOTE

When this parameter is set, the power must be turned off

before operation is continued.

[Data type] Bit

SGD Servo waveform

0 : Not displayed

1 : Displayed

12.1.7

Waveform Diagnosis

Display

General

Parameter
