B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

461

[Classification] Input signal

[Function] When M29 (miscellaneous function for preparation for rigid tapping) is

specified, the PMC enters rigid tapping mode, then turns on this signal

to notify the CNC.

1 : The PMC enters in rigid tapping mode.

0 : The PMC does not enter rigid tapping mode.

For an explanation of placing the PMC in rigid tapping mode, see the

description of the interface with the PMC, given later.

This signal posts whether the PMC has entered rigid tapping mode. If this

signal is not set to 1, even when M29 is specified, a P/S alarm is issued

in a G84 (G74) block.

[Classification] Output signal

[Function] During rigid tapping, these signals notify the PMC of whether the spindle

is rotating in the forward or reverse direction.

During rigid tapping, the spindle is:

RGSPP 1 : Rotating in the forward direction (CW).

0 : Not rotating in the forward direction.

RGSPM 1 : Rotating in the reverse direction (CCW).

0 : Not rotating in the reverse direction.

[Output condition] These signals are output when the spindle is rotating in rigid tapping

mode. This means that, even in rigid tapping mode, these signals are not

output, for example, when the spindle is being positioned to a hole

position, or a dwell operation is in progress at the bottom of a hole or at

an R point.

These signals are not output in the feed hold state or single block stop

state. When the spindle is placed in the interlock stop state, machine lock

state, or Z–axis ignore state, however, the spindle is not regarded as

having stopped; these signals are output.

These signals are valid only in rigid tapping mode. In normal spindle

control, these signals are not output; both RGSPP and RGSPM are set to

“0”.

9.10.6

Signal

9.10.6.1

Signals for the rigid

tapping function

Rigid tapping signal

RGTAP<G061#0>

Spindle rotation

direction signals

RGSPM, RGSPP

<F065#1, #0>

(M series only)
