4. REFERENCE POSITION ESTABLISHMENT

B–63503EN–1/01

158

[Classification] Output signal

[Function] These signals are used to post notification of the torque limit having been

reached for each corresponding axis during cycle operation for butt–type

reference position setting.

[Operation] Each signal is set to 1 when:

· The torque limit is reached for the corresponding axis during cycle

operation for butt–type reference position setting.

Each signal is set to 0 when:

· The torque limit is not reached for the corresponding axis during cycle

operation for butt–type reference position setting.

F180

#6 #5 #4 #3

CLRCH4

CLRCH3

CLRCH2

CLRCH1

1006

#6 #5

ZMIx

#4 #3 #2 #1 #0

NOTE

When this parameter is changed, turn off the power before

continuing operation.

[Data type] Bit axis

ZMIx The direction of reference position return and the direction of initial

backlash at power–on.

0 : Positive direction

1 : Negative direction

7181 First withdrawal distance in butt–type reference position setting

[Data type] 2–word axis

Increment system IS–B IS–C Unit

Millimeter machine 0.001 0.0001 mm

Inch machine 0.0001 0.00001 inch

Signal

Torque limit reach

signals for butt–type

reference position

setting CLRCH1 to

CLRCH4 <F180>
