1. AXIS CONTROL

Machine coordinate system is a coordinate system set with a zero point

proper to the machine system.

A coordinate system in which the reference position becomes the

parameter-preset (No. 1240) coordinate value when manual reference

position return is performed, is set. With G53 command, the machine

coordinate system is selected and the axis can be moved at rapid traverse

to the position expressed by the machine coordinates.

1240

Coordinate value of the reference position on each axis in the machine

coordinate system

NOTE

After setting this parameter, turn the power off then on again

so that the setting will take effect.

[Data type] Two–word axis

Increment system IS–A IS–B IS–C Unit

Metric machine 0.01 0.001 0.0001 mm

Inch machine 0.001 0.0001 0.00001 inch

Rotation axis 0.01 0.001 0.0001 deg

[Valid data range] –99999999 to 99999999

Set the coordinate values of the reference positions in the machine

coordinate system.

WARNING

Since the machine coordinate system must be set before

the G53 command is specified, at least one manual

reference position return or automatic reference position

return by the G28 command must be performed after the

power is turned on. This is not necessary when an

absolute–position detector is attached.

1.5

SETTINGS RELATED

WITH COORDINATE

SYSTEMS

1.5.1

Machine Coordinate

System

General

Parameter

[Unit of data]

Warning
