Series 0i - Model A Connection manual (Function) Page 447

Connection manual (Function)
B–63503EN–1/01
9. SPINDLE SPEED FUNCTION
431
3911 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (High gear)
3912 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Medium high gear)
3913 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Medium low gear)
3914 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Low gear)
[Data type] Word axis
[Unit of data] 0.01 sec
–1
[Valid data range] 0 to 32767
Set the servo loop gain of the servo axis that interpolates with Cs contour
control axis on each spindle gear (2nd group)
3920 Number of servo axis that interpolates with Cs contour control
[Data type] Byte axis
[Valid data range] 0 to 4
Set the number of servo axis that interpolates with Cs contour control axis
(3rd group)
NOTE
When there is no servo axis or less than three servo axes
that interpolates with Cs contour control axis, set this
parameter to 0.
3921 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (High gear)
3922 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Medium high gear)
3923 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Medium low gear)
3924 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Low gear)
[Data type] Word axis
[Unit of data] 0.01 sec
–1
[Valid data range] 0 to 32767
Set the servo loop gain of the servo axis that interpolates with Cs contour
control axis on each spindle gear (3rd group)
