B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

466

When bit 7 (SRS) of parameter No. 5200 is set to 1, to select a spindle to

be used for rigid tapping, set the signals as indicated below.

Signal state

Spindle used for rigid tapping

RGTSP1 RGTSP2

First spindle “1” “1”

First spindle “1” “0”

Second spindle “0” “1”

P/S alarm No. 205 is issued. “0” “0”

WARNING

These signals must be applied before the command for rigid

tapping (M29 S....; G84 X...) is specified. The states of

these signals must not be changed before rigid tapping has

been completed.

[Classification] Input signal

[Operation] These signals are used to stop each spindle when the multi–spindle

control is used. In a PMC sequence for rigid tapping, the ENB and ENB2

signals are used. Accordingly, the logic of the signals used for a spindle

selected to perform rigid tapping must match the logic of the spindle stop

signal *SSTP.

*SSTP1 1 : The output to the first spindle does not specify 0 min

–1

0 : The output to the first spindle specifies 0 min

–1

*SSTP2 1 : The output to the second spindle does not specify 0 min

–1

0 : The output to the second spindle specifies 0 min

–1

[Classification] Input signal

[Operation] This signal is used to select the second position coder when the

multi–spindle control option is being used. Note, however, that it cannot

be used with a spindle selected to perform rigid tapping.

1 : Control is exercised using a feedback pulse signal from the second

position coder.

0 : Control is exercised using a feedback pulse signal from the first

position coder.

For rigid tapping, this signal is not used. Instead, a position loop is

constructed by combining the first spindle with the first position coder,

or by combining the second spindle with the second position coder.

Spindle–by–spindle stop

signals

*SSTP1, *SSTP2

<G027#3, #4>

Second position coder

selection signal

PC2SLC<G028#7>
