Series 0i - Model A Connection manual (Function) Page 759

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

15. PMC CONTROL FUNCTION

743

[Classification] Input signal

[Function]

These signals can be used to select the override for the rapid traverse rate,

independently of the CNC, by setting bit 2 (OVE) of parameter No. 8001.

Rapid traverse override signals

ROV2E ROV1E

Override value

100%

50%

25%

F0 is the minimum feedrate specified with parameter No. 1421.

[Classification] Input signal

[Function] These signals can be used to perform dry run or manual rapid traverse,

independently of the CNC, by setting bit 2 (OVE) of parameter No. 8001.

When dry run signal DRNE is set to “1”, the specified rapid traverse rate

and cutting feedrate are ignored and the tool moves at the dry run speed

(set in parameter No. 1410) multiplied by the specified override. Bit 3

(RDE) of parameter No. 8001 can be used to specify whether to enable

or disable dry run for rapid traverse.

When manual rapid traverse selection signal RTE is set to “1” during dry

run, the tool moves at the rapid traverse rate for rapid traverse and at the

maximum jog feedrate for cutting feed. When the signal is set to “0”, the

tool moves at the jog feedrate. When dry run signal DRNE is set to “0”,

the specified rapid traverse rate or cutting feedrate is restored.

Feedrate of Dry run

Manual rapid

Command from PMC

traverse select

signal

Rapid traverse Feed

1 Rapid traverse rate Maximum cutting

feedrate

0 Dry run feed

rate JV(*)

Dry run feed

rate JV

* Can also be set to the rapid traverse rate with bit 3 (RDE) of parameter

No. 8001.

28 Rapid traverse

override signals

ROV1E and ROV2E

29 Dry run signal DRNE

30 Manual rapid traverse

selection signal RTE
