Series 0i - Model A Connection manual (Function) Page 270

Connection manual (Function)
B–63503EN–1/01
7. FEEDRATE CONTROL/ACCELERATION
AND DECELERATION CONTROL
254
#7
8131
#6 #5 #4 #3 #2
EDC
#1 #0
NOTE
When this parameter has been set, the power must be
turned off before operation is continued.
[Data type] Bit
EDC Specifies whether to use external deceleration, as follows :
0 : Not to use.
1 : Use.
1450
Change of feedrate for one graduation on the manual pulse
generator during F1 digit feed
[Data type] Byte
[Valid data range] 1 to 127
Set the constant that determines the change in feedrate as the manual pulse
generator is rotated one graduation during F1-digit feed.
F +
Fmaxi
100n
∆
(where, i=1 or 2)
In the above equation, set n. That is, the number of revolutions of the
manual pulse generator, required to reach feedrate Fmaxi is obtained.
Fmaxi refers to the upper limit of the feedrate for an F1-digit feed
command, and set it in parameter 1460 or 1461.
Fmax1: Upper limit of the feedrate for F1 to F4 (parameter 1460)
Fmax2: Upper limit of the feedrate for F5 to F9 (parameter 1461)
1451 Feedrate for F1 digit command F1
1452 Feedrate for F1 digit command F2
1453 Feedrate for F1 digit command F3
1454 Feedrate for F1 digit command F4
1455 Feedrate for F1 digit command F5
1456 Feedrate for F1 digit command F6
1457 Feedrate for F1 digit command F7
1458 Feedrate for F1 digit command F8
1459 Feedrate for F1 digit command F9
Input for setting is enabled.
