0i/0i Mate - Model C Connection manual (Function) Page 101

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

1. AXIS CONTROL

G50 When the CNC has commands G54 to G59 specifying workpiece

coordinate systems (optional function), if the G50 command for setting a

coordinate system (or the G92 command in G command system B or C) is

specified,

0 : The G50 (or G92) command is executed without an alarm.

1 : P/S alarm No. 010 is issued and the G50 (or G92) command is not

executed.

1220 External workpiece zero point offset value

[Data type] Two–word axis

Input increment IS–A IS–B IS–C Unit

Linear axis (input in mm) 0.01 0.001 0.0001 mm

Linear axis (input in inches) 0.001 0.0001 0.00001 inch

Rotation axis 0.01 0.001 0.0001 deg

[Valid data range] –99999999 to 99999999

This is one of the parameters that give the position of workpiece

coordinate system (G54 to G59). It gives an offset of the workpiece zero

point common to all workpiece coordinate systems. In general, the offset

varies depending on the workpiece coordinate systems. The parameter

value can also be set from the PMC by using the external data input

function.

1221 Workpiece zero point offset value in workpiece coordinate system1 (G54)

1222 Workpiece zero point offset value in workpiece coordinate system2 (G55)

1223 Workpiece zero point offset value in workpiece coordinate system3 (G56)

1224 Workpiece zero point offset value in workpiece coordinate system4 (G57)

1225 Workpiece zero point offset value in workpiece coordinate system5 (G58)

1226 Workpiece zero point offset value in workpiece coordinate system6 (G59)

[Data type] Two–word axis

Input increment IS–A IS–B IS–C Unit

Linear axis (input in mm) 0.01 0.001 0.0001 mm

Linear axis (input in inches) 0.001 0.0001 0.00001 inch

Rotation axis 0.01 0.001 0.0001 deg

[Valid data range] –99999999 to 99999999

The workpiece zero point offset values in workpiece coordinate systems 1

to 6 (G54 to G59) are set.

[Unit of data]
