15. PMC CONTROL FUNCTION
1047
#7 #6 #5 #4 #3 #2 #1 #0
G000
G001
G002
ED7 ED6 ED5 ED4 ED3 ED2 ED1 ED0
ED15 ED14 ED13 ED12 ED11 ED10 ED9 ED8
ESTB EA6 EA5 EA4 EA3 EA2 EA1 EA0
F060
ESEND EREND
#7 #6 #5 #4 #3 #2 #1 #0
ESCAN
#7
3202
#6
PSR
#5 #4 #3 #2 #1 #0
[Data type] Bit
PSR Search for the program number of a protected program
0 : Disabled
1 : Enabled
#7
6300
#6 #5 #4
ESR
#3
ESC
#2 #1 #0
[Data type] Bit
ESC Specifies whether the external program number search function is to
execute a search if a reset signal is input between the time the ESTB signal
(read signal for external data input) is input and the time the search would
be executed, as follows:
0 : The search is executed after the CNC is reset.
1 : No search is executed.
ESR External program number search
0 : Disabled
1 : Enabled
6310 Number of added message numbers of external operator messages
[Data type] Word
[Valid data range] 0, 1 to 1000
For external operator messages within the range set in this parameter,
message numbers each obtained by adding 2000 to the relevant message
number are indicated.
Signal address
Parameter
