11. PROGRAM COMMAND
797
5167 Percentage of the cutting feedrate to be changed when the tool is retracted without
an overload torque signal received
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 255
This parameter sets the percentage of the cutting feedrate change during a
peck drilling cycle.
F2 = F1 b2 B 100
F1: Cutting feedrate to be changed
F2: Changed cutting feedrate
b2 is set as a percentage.
5168 Lower limit of the percentage of the cutting feedrate in a peck drilling cycle of a
small diameter
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 255
This parameter sets the lower limit of the percentage of feedrate change
for in a peck drilling cycle.
FL = F b3 B 100
F: Specified cutting feedrate
FL: Changed cutting feedrate
Set b3 as a percentage.
5170 Macro variable where the total number of retractions is recorded
[Data type] Word
[Valid data range] 100 to 149
This parameter identifies the macro variable where the total number of
times the tool is retracted is recorded. The macro variables cannot be
variables 500 to 599.
5171 Macro variable to which the total umber of retractions due to an overload
signal is recorded
[Data type] Word
[Valid data range] 100 to 149
This parameter identifies the custom macro variable where the number of
times the tool is retracted after the overload signal is recorded. The macro
variable cannot be variables 500 to 599.
