0i/0i Mate - Model C Connection manual (Function) Page 745

Connection manual (Function)
B–64113EN–1/01
11. PROGRAM COMMAND
727
Table 11.2 G code list for T series (2/3)
G code
Group
Function
A B C
Group
Function
G36 G36 G36
00
Automatic tool compensation X (When the bit 3 (G36) of
parameter No. 3405 is set to 0)
G37 G37 G37
00
Automatic tool compensation Z
G37.1 G37.1 G37.1
00
Automatic tool compensation X
G37.2 G37.2 G37.2 Automatic tool compensation Z
G39 G39 G39 Corner circular interpolation
G40 G40 G40
07
Tool nose radius compensation cancel
G41 G41 G41
07
Tool nose radius compensation left
G42 G42 G42 Tool nose radius compensation right
G50 G92 G92
00
Coordinate system setting or max. spindle speed setting
G50.3 G92.1 G92.1
00
Workpiece coordinate system preset
G50.2
(G250)
G50.2
(G250)
G50.2
(G250)
20
Polygonal turning cancel
G51.2
(G251)
G51.2
(G251)
G51.2
(G251)
20
Polygonal turning
G52 G52 G52
00
Local coordinate system setting
G53 G53 G53
00
Machine coordinate system setting
G54 G54 G54
14
Workpiece coordinate system 1 selection
G55 G55 G55
14
Workpiece coordinate system 2 selection
G56 G56 G56
14
Workpiece coordinate system 3 selection
G57 G57 G57
14
Workpiece coordinate system 4 selection
G58 G58 G58 Workpiece coordinate system 5 selection
G59 G59 G59 Workpiece coordinate system 6 selection
G60 G60 G60
00
Single direction positioning
G65 G65 G65
00
Macro calling
G66 G66 G66
12
Macro modal call
G67 G67 G67
12
Macro modal call cancel
G68 G68 G68
04
Mirror image for double turrets ON
G69 G69 G69
04
Mirror image for double turrets OFF
G70 G70 G72
00
Finishing cycle
G71 G71 G73
00
Stock removal in turning
G72 G72 G74
00
Stock removal in facing
G73 G73 G75
00
Pattern repeating
G74 G74 G76 End face peck drilling
G75 G75 G77 Outer diameter/internal diameter drilling
G76 G76 G78 Multiple threading cycle
