0i/0i Mate - Model C Connection manual (Function) Page 1186

Connection manual (Function)
B–64113EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
1168
Function Section
M
series
T
series
AddressSymbolSignal name
Rigid tapping
Rigid tapping signal RGTAP G061#0 f f
9.10
Rigid tapping
Spindle rotation direction signals
RGSPP F065#0 — f
9.10
Rigid tapping
Spindle rotation direction signals
RGSPM F065#1 — f
9.10
Rigid tapping–in–progress signal RTAP F076#3 f f
Rigid tapping spindle selection signals RGTSP1, RGTSP2 G061#4, #5 f —
Retraction for rigid
Rigid tapping retraction start signal RTNT G062#6 — f
5.11
Retraction for rigid
tapping
Rigid tapping retraction completion
signal
RTPT F066#1 — f
5.11
Reset and rewind
External reset signal ERS G008#7 f f
5.2
Reset and rewind
Reset & rewind signal RRW G008#6 f f
5.2
Reset and rewind
Resetting signal RST F001#1 f f
5.2
Rewinding signal RWD F000#0 f f
Interrupt type custom
macro
Interrupt signal for custom macro UINT G053#3 f f
11.5.2
