0i/0i Mate - Model C Connection manual (Function) Page 422

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

404

If an overtravel alarm occurs during linear acceleration/deceleration

before interpolation, the movement is decelerated and stopped. As

deceleration and stop are performed after the alarm occurs, the tool will

overrun by an amount equal to the distance required for the deceleration.

The actual overrun depends on the feedrate when the overtravel alarm

occurs.

The distance can be minimized by starting deceleration in advance, such

that the feedrate has fallen to the value specified in parameter No. 1784

when an overtravel alarm occurs. Because deceleration is executed such

that the feedrate at the time an overtravel alarm occurs does not exceed

the feedrate specified in the corresponding parameter, deceleration may

be completed earlier. After deceleration is completed, the feedrate

specified in the parameter is maintained.

Deceleration is performed when the following condition is

satisfied:

Distance to stored stroke limit 1

for each axis

Distance needed to reduce the cur-

rent feedrate (tangential feedrate)

to that specified in parameter No.

1784

The overrun is calculated as follows:

Overrun x

[FIX (

) ) 1.5]

1875

F : Maximum cutting feedrate in linear acceleration/deceleration before

interpolation (parameter No. 1770)

T : Time needed to attain the maximum cutting feedrate in linear

acceleration/deceleration before interpolation

For a linear axis (command not involving a rotation axis):

Parameter No. 1771

For a rotation axis (command involving a rotation axis):

Parameter No. 1786

For a linear axis (command not involving a rotation axis):

Parameter No. 1772

For a rotation axis (command involving a rotation axis):

Parameter No. 1787

: Feedrate at the time an overtravel alarm occurs during linear accel-

eration/deceleration before interpolation (parameter No. 1784)

FIX: Any fractional part is truncated.

NOTE

A time required to reach the maximum machining feedrate

based on acceleration/deceleration before interpolation in

the advanced preview control mode can be set separately

for a linear axis and rotation axis. Note, however, that the

tool decelerates and stops between a block specifying a

command not involving a rotation axis and a block

specifying a command involving a rotation axis.
