A. INTERFACE BETWEEN CNC AND PMC

1181

Group

Referen

ce item

series

Address Signal nameSymbol

SFRA

CW command signal (serial spindle)

G070#5 f f

9.2

SFRB

CW command signal (serial spindle)

G074#5 f f

9.2

SGN

Spindle motor command polarity select signal

G033#5 f f

15.4

SGN2

Spindle motor command polarity select signal

G035#5 f f

15.4

SGN3 G037#5 f f

SHA00 to SHA11

Spindle orientationexternal stop position command

signal

G078#0 to

G079#3

f f

9.12

SHB00 to SHB11

Spindle orientationexternal stop position command

signal

G080#0 to

G081#3

f f

9.12

SIND

Spindle motor speed command select signal

G033#7 f f

15.4

SIND2

Spindle motor speed command select signal

G035#7 f f

15.4

SIND3 G037#7 f f

SKIP

Skip signal X004#7 f f 14.3.1

SKIP

Overload torque signal X004#7 – f 11.14

SKIP2 to SKIP6,

SKIP7,SKIP8

Skip signal

X004#2 to #6,

#0,#1

f f 14.3.3

SKIPP Skip signal G006#6 f – 14.3.1

SLVA

Slave operation command signal (serial spindle)

G073#1 f f

9 2

SLVB

Slave operation command signal (serial spindle)

G077#1 f f

9 2

SLVSA

Slave operation status signal (serial spindle)

F046#4 f f

SLVSB

Slave operation status signal (serial spindle)

F050#4 f f

SMZ Error detect signal G053#6 f – 7.2.5.3

SOCNA

Soft start/stop cancel signal (serial spindle)

G071#4 f f

9.2

SOCNB

Soft start/stop cancel signal (serial spindle)

G075#4 f f

9.2

SOR Spindle orientationsignal G029#5 f f

9.3

SOV0 to SOV7 Spindle speed override signal G030 f f

9.3

SPAL Spindle fluctuationdetection alarm signal F035#0 f f 9.5

SPL Feed hold lamp signal F000#4 f f 5.1

SPO Software operator's panel signal(*SP) F075#7 f f 12.1.14

SPPHS Spindle phase synchronous control signal G038#3 f f 9.11

SPSLA

Spindle select signal (serial spindle)

G071#2 f f

9.2

SPSLB

Spindle select signal (serial spindle)

G075#2 f f

9.2

SPSTP Spindle stop complete signal G028#6 f – 9.7

SPSYC Spindle synchronous control signal G038#2 f f 9.11

SRLNI0 to SRLNI3 Group number specification signals G091#0 to #3 f f

13.5

SRLNO0 to SRLNO3 Group number output signals F178#0 to #3 f f

13.5

SRN Program restart signal G006#0 f f

5.7

SRNMV Program restart under way signal F002#4 f f

5.7

SRVA

CCW command signal (serial spindle)

G070#4 f f

9.2

SRVB

CCW command signal (serial spindle)

G074#4 f f

9.2
