0i/0i Mate - Model C Connection manual (Function) Page 1176

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

1158

Function Section

series

AddressSymbolSignal name

Spindle serial

Analog override signals (serial spindle)

OVRA G072#4 f f

9.2

Spindle serial

Analog override signals (serial spindle)

OVRB G076#4 f f

9.2

Spindle serial

Incremental command externally set

orientation signals (serial spindle)

INCMDA G072#5 f f

9.2

Spindle serial

Incremental command externally set

orientation signals (serial spindle)

INCMDB G076#5 f f

9.2

Spindle serial

Spindle switch MAIN MCC contact

status signals (serial spindle)

MFNHGA G072#6 f f

9.2

Spindle serial

Spindle switch MAIN MCC contact

status signals (serial spindle)

MFNHGB G076#6 f f

9.2

Spindle serial

Spindle switch HIGH MCC contact

status signals (serial spindle)

RCHHGA G072#7 f f

9.2

Spindle serial

Spindle switch HIGH MCC contact

status signals (serial spindle)

RCHHGB G076#7 f f

9.2

Spindle serial

Magnetic sensor orientation command

signals (serial spindle)

MORCMA G073#0 f f

9.2

Spindle serial

Magnetic sensor orientation command

signals (serial spindle)

MORCMB G077#0 f f

9.2

Spindle serial

Subordinate operation mode command

signals (serial spindle)

SLVA G073#1 f f

9.2

Spindle serial

Subordinate operation mode command

signals (serial spindle)

SLVB G077#1 f f

9.2

Spindle serial

Motor power cutoff command signals

(serial spindle)

MPOFA G073#2 f f

9.2

Spindle serial

Motor power cutoff command signals

(serial spindle)

MPOFB G077#2 f f

9.2

Spindle serial

Disconnection detection disbale signal

DSCNA G073#4 f f

9.2

Spindle serial

Disconnection detection disbale signal

DSCNB G077#4 f f

9.2

Spindle serial

Alarm signals (serial spindle)

ALMA F045#0 f f

9.2

Spindle serial

Alarm signals (serial spindle)

ALMB F049#0 f f

9.2

Spindle serial

output/spindle

Speed zero signals (serial spindle)

SSTA F045#1 f f

9.2

output/spindle

analog output

Speed zero signals (serial spindle)

SSTB F049#1 f f

9.2

Speed detection signals (serial spindle)

SDTA F045#2 f f

Speed detection signals (serial spindle)

SDTB F049#2 f f

Speed arrival signals (serial spindle)

SARA F045#3 f f

Speed arrival signals (serial spindle)

SARB F049#3 f f

Load detection signals 1 (serial spindle)

LDT1A F045#4 f f

Load detection signals 1 (serial spindle)

LDT1B F049#4 f f

Load detection signals 2 (serial spindle)

LDT2A F045#5 f f

Load detection signals 2 (serial spindle)

LDT2B F049#5 f f

Torque limit signals (serial spindle)

TLMA F045#6 f f

Torque limit signals (serial spindle)

TLMB F049#6 f f

Orientation completion signals

(serial spindle)

ORARA F045#7 f f

Orientation completion signals

(serial spindle)

ORARB F049#7 f f

Power line switch signals

(serial spindle)

CHPA F046#0 f f

Power line switch signals

(serial spindle)

CHPB F050#0 f f

Spindle switch completion signals

(serial spindle)

CFINA F046#1 f f

Spindle switch completion signals

(serial spindle)

CFINB F050#1 f f

Output switch signals (serial spindle)

RCHPA F046#2 f f

Output switch signals (serial spindle)

RCHPB F050#2 f f
