0i/0i Mate - Model C Connection manual (Function) Page 124

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

1. AXIS CONTROL

106

8302

#6 #5 #4 #3 #2 #1

ATS

ATE

NOTE

The system power must be turned off then back on in order

for this parameter setting to become effective.

[Data type] Bit

ATE Specify whether to enable the automatic setting of grid positioning under

simple synchronous control (one master/slave axis pair)

0 : Disabled

1 : Enabled

ATS Specify whether to start the automatic setting of grid positioning under

simple synchronous control (one master/slave axis pair)

0 : Not started

1 : Started

NOTE

1 Setting this parameter resets parameter APZx (bit 4 of

parameter No. 1815) for the master and slave axes and

parameter No. 8316 to 0.

2 This parameter automatically becomes 0 upon the

completion of grid positioning.

SOFx8303

#6 #5 #4 #3 #2 #1

ATSx

ATEx

[Data type] Bit axis

ATEx Specify whether to enable the automatic setting of grid positioning under

simple synchronous control (two master/slave axis pair)

0 : Disabled

1 : Enabled

ASTx Specify whether to start the automatic setting of grid positioning under

simple synchronous control (two master/slave axis pair)

0 : Not started

1 : Started

NOTE

To start the automatic setting of grid positioning, set ATSx

to 1. ATSx automatically becomes 0 upon the completion

of automatic setting.

SOFx Specify whether to enable synchronization compensation during simple

synchronous control (two master/slave axis pair)

0 : Disabled

1 : Enabled
