0i/0i Mate - Model C Connection manual (Function) Page 986

Connection manual (Function)
14. MEASUREMENT
B–64113EN–1/01
968
Number Message Description
015 TOO MANY AXES COM-
MANDED
In the block including the command for
the skip function (G31 P99/P98), to be
executed under the control of the
torque limit reach signal, no axis move
command is specified, or two or more
axes are specified.
In a single block, specify one axis only.
244 P/S ALARM When the skip function to be executed
under the control of the torque limit
reach signal is enabled, an error value
(32767) that exceeds the maximum re-
turn value that can be handled with a
single distribution is detected before in-
put of the torque limit reach signal.
Retry the processing after changing the
axis feedrate, torque limit, or other
conditions.
CAUTION
1 Specify a torque limit before G31 P99/P98.
If G31 P99/P98
is executed with no torque limit specified, the move
command is executed without a skip operation.
2 When G31 P99 is specified, the SKIP signal causes a skip
operation. However, avoid using the high–speed skip
operation.
3 Before specifying G31 P99/P98, cancel tool–tip radius
compensation with G40.
4 Set the SKF bit (bit 7 of parameter No. 6200) to 0 to disable
the dry run, override, and automatic
acceleration/deceleration functions for the G31 skip
command.
Series 0i–C
OPERATOR’S MANUAL
(T series) (B–64114EN)
II.4.12 TORQUE LIMIT SKIP
Series 0i Mate–C
OPERATOR’S MANUAL
(T series) (B–64134EN)
II.4.11 TORQUE LIMIT SKIP
Alarm and message
Caution
Reference item
