14. MEASUREMENT
963
#7
SKIP
X004
#6
ESKIP
SKIP6
#5
–MIT2
SKIP5
#4
+MIT2
SKIP4
#3
–MIT1
SKIP3
#2
+MIT1
SKIP2
#1
ZAE
SKIP8
#0
XAE
SKIP7
SKIP
ESKIP
SKIP6
SKIP5 SKIP4 SKIP3
ZAE
SKIP2
YAE
SKIP8
XAE
SKIP7
(T series)
(M series)
WARNING
1 SKIP2 to SKIP6 are at the same addresses as skip signal
ESKIP (axis control by PMC) and axial manual feed
interlock signals +MIT1, –MIT1, +MIT2, and –MIT2 (direct
input B for tool compensation measurements). Be careful
when using both. (T series)
2 SKIP2 and SKIP6 to SKIP8 are at the same addresses as
skip signal ESKIP (axis control by PMC) and measurement
position arrival signal XAE, YAE, and ZAE (tool length
automatic measurement). Be careful when using both. (M
series)
CAUTION
If the automatic tool compensation is used, SKIP5 to SKIP8
cannot be used. (T series)
#7
6200
#6 #5
SLS
#4
HSS
#3 #2 #1 #0
[Data type] Bit type
HSS 0 : The skip function does not use high-speed skip signals.
1 : The skip function uses high-speed skip signals.
SLS 0 : The multi–step skip function does not use high-speed skip signals
while skip signals are input.
1 : The multi–step skip function uses high-speed skip signals while skip
signals are input.
NOTE
Skip signals (SKIP and SKIP2 to SKIP8) do not depend on
the setting of this parameter. They are always enabled.
And, it is possible to set disable with parameter IGX bit 4 of
No. 6201.
Signal address
Parameter
Previous page
Next page
