12. DISPLAY/SET/EDIT

B–64113EN–1/01

882

The number of registered programs is 400.

Number Message Description

072 TOO MANY PROGRAMS The number of programs to be stored

exceeded 400. Delete unnecessary

programs and execute program

registeration again.

Series 0i–C

OPERATOR’S MANUAL

(M series) (B–64124EN)

III.11.3.1

Displaying Memory Used and a

List of Programs

Series 0i–C

OPERATOR’S MANUAL

(T series) (B–64114EN)

III.11.3.1

Displaying Memory Used and a

List of Programs

Series 0i Mate–C

OPERATOR’S MANUAL

(M series) (B–64144EN)

III.11.3.1

Displaying Memory Used and a

List of Programs

Series 0i Mate–C

OPERATOR’S MANUAL

(T series) (B–64134EN)

III.11.3.1

Displaying Memory Used and a

List of Programs

A key called the data protection key is used to prevent part programs,

offset values, parameters, and setting data from being registered,

modified, or deleted erroneously.

[Classification] Input signal

[Function] Enables the changing of the memory contents from the MDI panel. Four

signals are provided. The operations that can be performed on the

contents of memory by each signal vary depending on the setting of bit

7 (KEY) of parameter No. 3290.

12.2.2

No. of Registered

Programs

General

Alarm and message

Reference item

12.2.3

Memory Protection Key

General

Signal

Memory protection

signal

KEY1 to KEY4

<G046#3 to #6>
