B–64113EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

1155

Function Section

series

AddressSymbolSignal name

Tool life management

Tool change signal TLCH F064#0 f f

10.3

Tool life management

Tool change reset signal TLRST G048#7 f f

10.3

Tool life management

Individual tool change signal TLCHI F064#2 — f

Tool life management

Tool life arrival notice signal TLCHB F064#3 — f

10.3.2

Tool life management

Individual tool change reset signal TLRSTI G048#6 — f

10.3

Tool life management

Tool skip signal TLSKP G048#5 f f

10.3

New tool selection signal TLNW F064#1 f f

10.3

Tool group number selection signals

TL01 to TL256

G047#0 to

G048#0

— f

10.3

Tool group number selection signals

TL01 to TL64 G047#0 to #6 f —

Tool life count override signals *TLV0 to *TLV9

G049#0 to

G050#1

— f

Automatic tool length

Measuring position reached signals

XAE X004#0 f f

14.2

Automatic tool length

measurement (M

series)/automatic

Measuring position reached signals

YAE X004#1 — f

14.2

measurement (M

series)/automatic

tool offset (T series)

Measuring position reached signals

ZAE X004#2 — f

14.2

tool offset (T series)

ZAE X004#1 f —

Direct input of tool

Tool offset value write mode selection

signal

GOQSM G039#7 f —

14.4.2

Direct input of tool

Tool offset value write signals

+MIT1, +MIT2 X004#2, #4 f —

14.4.2

Direct input of tool

offset value

Tool offset value write signals

–MIT1, –MIT2 X004#3, #5 f —

14.4.2

offset value

measured B (T

series)

Tool offset number selection signals OFN0 to OFN5 G039#0 to #5 f —

14.4.2

series)

Workpiece coordinate system shift

value write mode selection signal

WOQSM G039#6 f —

Workpiece coordinate system shift

value write signal

WOSET G040#7 f —

Input of tool offset

value measured A (T

series)

Position record signal PRC G040#6 f —

14.4.1

High–speed M/S/T/B

Miscellaneous function completion

signal

MFIN G005#0 f f

8.4

High–speed M/S/T/B

Spindle function completion signal SFIN G005#2 f f

8.4

High–speed M/S/T/B

Tool function completion signal TFIN G005#3 f f

8.4

High–speed M/S/T/B

2nd auxiliary function completion signal

BFIN G005#4 f —

8.4

High–speed M/S/T/B

interface

2nd auxiliary function completion signal

BFIN G005#7 — f

8.4

interface

2nd M function completion signal MFIN2 G004#4 f f

8.4

3rd M function completion signal MFIN3 G004#5 f f

External operation signal for

high–speed interface

EFD F007#1 — f

External operation function completion

signal

EFIN G005#1 — f

High–speed skip

signal

High–speed skip status signals HDO0 F122#0 f f

14.3.2

Trouble diagnosis Trouble forecast signals TDFSV1 to TDFSV4 F298#0 to #3 f f

18.1
