0i/0i Mate - Model C Connection manual (Function) Page 738

Connection manual (Function)

Page of 1224

/ 1224

10. TOOL FUNCTIONS

B–64113EN–1/01

720

#7 #6 #5 #4 #3 #2 #1 #0

5003 CCN

[Data type] Bit

CCN When automatic reference position return (G28) is specified in the cutter

compensation C mode (M series) or in tool nose radius compensation (T

series):

0 : The cutter compensation vector is cancelled in movement to an

intermediate position.

1 : The cutter compensation vector is not cancelled in movement to an

intermediate position, but is cancelled in movement to the reference

position.

#7 #6 #5 #4 #3 #2 #1 #0

5008 QCR MCR CNV CNC CNI

[Data type] Bit

CNI Interference check for cutter compensation C (M series) or tool–tip radius

compensation (T series) is:

0 : Performed

1 : Not performed

CNC During interference check for cutter compensation C (M series) or

tool–tip radius compensation (T series), when the direction of movement

after application of the offset differs from the programmed direction by

between 90_ and 270_:

0 : An alarm is issued.

1 : No alarm is issued.

CNV The interference check and vector erasure of cutter compensation C (M

series) or tool–nose radius compensation (T series) are:

0 : Performed.

1 : Not performed.

MCR If G41/G42 (cutter compensation C (M series) or tool–nose radius

compensation (T series)) is specified in the MDI mode, an alarm is:

0 : Not raised.

1 : Raised. (P/S5257)

NOTE

In the MDI mode, cutter compensation C (M series) or

tool–nose radius compensation (T series) is not performed,

irrespective of the setting of this parameter.

QCR The travel distance of circular interpolation in cutter compensation C (M

series) or tool–nose radius compensation (T series) is judged:

0 : In the FS16 format.

1 : In the FS15 format.

FS16 and FS15 determine the travel distance in different ways if the

radius of arc at the start point of circular interpolation is different from that

at the end point (if the end point is not on the arc). By this parameter, the

method of determining the travel distance of circular interpolation can be

selected.
